Introducing Autonomic’s 4th generation music server—the M3. Designed to deliver unparalleled audio performance for both residential and commercial applications, the M3 offers seamless integration with leading home automation systems. With over 18 years of refinement, this next-gen server grants access to a vast catalog of streaming music services and personal libraries, elevating your audio experience to true high-fidelity sound.
Three Independent Audio Streams
Stream up to three high-resolution music programs with ease.
Audiophile-Grade DACs
32-bit, 768kHz resolution for crystal-clear sound.
Pro-Installer Design
Includes redesigned UI, dual-purpose rack ears, and commercial-grade build.
DSP Engine
Adjust bass, treble, gain, and EQ for precise audio tuning.
Seamless Control Integration
Native AirPlay2, HomeKit compatibility, and doorbell sensing via input triggers.
Flexible Storage Options
Optional internal NVMe SSD for large, high-resolution music libraries.
M3 Product Specification Sheet
M3 Product Manual
Autonomic Music Without LimitsControl Modules
Autonomic AMX Module
Autonomic Control4 Module
Autonomic Crestron Module
Autonomic RTI Module
Autonomic URC Module- Streaming Services:
- Deezer, iHeartRadio, Murfie, Napster, PANDORA® Internet Radio, SiriusXM Internet Radio, Slacker Radio, Spotify, TIDAL, TuneIn
- Audio Formats:
- .aif, .aifc, .aiff, .alac, .au, .cda, .flac, .m4a, .mp2, .mp3, .mpa, .rmi, .snd, .wav, .wma, .wpl
- Internal Storage:
- Optional 1TB M.2 NVMe Drive
- External Storage:
- Expandable via USB external hard drives or network shared storage
- Audio Outputs (3 Total):
- (Analog RCA: Output A, B, C) (Digital Coax: Output A, B, C) (Optical: Output A, B, C) (HDMI: Assignable) (eAudioCast: Outputs A, B, C)
- Audio Inputs (2 Total):
- (1) Analog RCA (1) Digital Coax
- Analog Output:
- Unbalanced, stereo RCA type, line level audio output
- COAX:
- Stereo Coaxial, RCA type, SPDIF (PCM)
- Optical:
- Toslink, PCM
- USB:
- (1) USB 3.x
- HDMI:
- Stereo HDMI, Type A, PCM
- LAN Connection:
- (1) 8-wire RJ45 with 2 LED indicators; 10/100/1000 Mbits/sec BaseT Ethernet port; green LED indicates link status; yellow LED indicates Ethernet activity
- THD+N:
- 0.005%, 1kHz, 2VRMS Line Out
- S/N Ratio, Line Input to Line Output:
- 106db, 20 - 20kHz, A-weighted
- S/N Ratio, Digital Input to Line Output:
- 106db, 20 - 20kHz, A-weighted
- Dynamic Range:
- 100dB
- Max Line-In Level:
- 4.0V RMS
- Max Line-Out Level:
- 2.2V RMS
- Input Impedance:
- 10Kohm
- Output Impedance:
- 300 Ohm
- Digital-to-Analog Conversion:
- ESS Sabre
- Analog-to-Digital Conversion:
- ESS Sabre
- Supported Sample Rates:
- 44.1/48/96/192 kHz at 16-bit or 24-bit resolution
- Local Synchronization:
- Mirage Media Sync for both Mac and Windows: download from web-based configuration under Firmware tab
- Trigger Outputs:
- (3) Trigger Outputs (12v 100mA)
- Trigger Inputs:
- (4) Trigger Opto-Isolated Inputs (5-24v AC/DC)
- Other I/O:
- Reset Button, Power Button
- Control System Protocols:
- IP, 2-way documented API
- Control Interfaces:
- Control4, Crestron, Crestron Home, Elan, KNX, Leviton, Lutron, ON Controls, RTI, Savant, URC, AMX, Command Fusion, Windows/Mac, on-screen display (OSD), mobile devices and computers, Mirage Media Controller for iOS and/ or Android devices
- Power Connection:
- 110V-240V IEC 60320-1C13/C14 power cord (included)
- Main Power Consumption:
- 30W MAX @ 100–240 V AC, 50–60Hz
- Standby Power:
- 0.3W
- Power Cord (USA/Canada):
- IEC C13 to NEMA 5-15, 3 Wire, 18Ga, 6ft
- Temperature:
- 32°F to 104°F (0°C to 40°C)
- Humidity:
- 10% to 90% RH (non-condensing)
- Heat Dissipation:
- 102 BTU/hr (Max)
- Height:
- 1.74" (44mm) 1RU
- Height (with feet):
- 2.25" (57mm)
- Width:
- 17.2" (437mm)
- Depth:
- 10.0" (254mm)
- Unit Weight:
- 5 lbs (2.3 kg)
- Shipping Weight:
- ~10lbs (4.6kg)
- Mounting:
- Four (4) screw on feet included; two rack ears included, can be wall mounted vertically by rotating rack ears
- Warranty:
- 2-year limited warranty
